Karta graficzna ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme, specyfikacje i wzorce

This section outlines the key features of the graphics card ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme.

• Na podstawie
  NVIDIA GeForce RTX 2080 Ti
• Układ GPU
  TU102
• Jednostki wykonawcze
  68
• Shader
  4352
• Jednostki wyjściowe renderingu
  88
• Jednostki tekstury
  272

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Rozmiar pamięci
  11 GB
• Typ pamięci
  GDDR6
• Szybkość pamięci
  1.8 GHz
• Pasmo pamięci
  634 GB/s
• Interfejs pamięci
  352 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme.

• Częstotliwość podstawowa
  1.350 GHz
• Maksymalna częstotliwość
  1.815 GHz+ 17 %
• Avg (Game) Clock
  1.545 GHz
• Overclocking
  Tak

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  300 W+ 20 %
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Wentylator 1
  3 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Wentylator 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Wyświetlacze
  4
• HDCP-Version
  2.2
• Porty HDMI
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4a
• Porty DVI
  --
• VGA Ports
  --
• USB-C Ports
  1

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Maks. rozdzielczość
  7680x4320
• DirectX
  12_2
• Raytracing
  Tak
• DLSS / FSR
  Tak
• LED
  ZOTAC SPECTRA

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Nie

• Długość
  324 mm
• Wysokość
  136 mm
• Width
  59 mm
• Szerokość (szczeliny)
  3 PCIe-Slots
• Weight
  --

• Interfejs GPU
  PCIe 3.0 x 16
• Data wydania
  Q3/2018
• Release price
  --
• Proces technologiczny
  12 nm
• Część nr
  ZT-T20810B-10P
• specyfikacja
  data sheet

Wspólne stanowiska ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme GPU w popularnych benchmarkach, dla porównania z innymi modelami.

• FP32 Performance (Single-precision TFLOPS)
  758 place
• Battlefield 5
  419 place
• Shadow of the Tomb Raider
  487 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  520 place
• Crypto-Mining Ergo Hashrate (MH/s)
  746 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  365 place
• 3DMark Benchmark
  390 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  345 place
