Karta graficzna ASUS ROG Matrix GeForce RTX 2080 Ti Platinum, specyfikacje i wzorce

This section outlines the key features of the graphics card ASUS ROG Matrix GeForce RTX 2080 Ti Platinum.

• Na podstawie
  NVIDIA GeForce RTX 2080 Ti
• Układ GPU
  TU102
• Jednostki wykonawcze
  68
• Shader
  4352
• Jednostki wyjściowe renderingu
  88
• Jednostki tekstury
  272

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Rozmiar pamięci
  11 GB
• Typ pamięci
  GDDR6
• Szybkość pamięci
  1.85 GHz
• Pasmo pamięci
  651 GB/s
• Interfejs pamięci
  352 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS ROG Matrix GeForce RTX 2080 Ti Platinum.

• Częstotliwość podstawowa
  1.350 GHz
• Maksymalna częstotliwość
  1.815 GHz+ 17 %
• Avg (Game) Clock
  1.800 GHz
• Overclocking
  Tak

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  260 W+ 4 %
• TDP (up)
  320 W
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS ROG Matrix GeForce RTX 2080 Ti Platinum.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Wentylator 1
  3 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Wentylator 2
  --
• Noise (Load)
  42 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Wyświetlacze
  4
• HDCP-Version
  2.2
• Porty HDMI
  2x HDMI v2.0b
• DP Ports
  2x DP v1.4a
• Porty DVI
  --
• VGA Ports
  --
• USB-C Ports
  1

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Maks. rozdzielczość
  7680x4320
• DirectX
  12_2
• Raytracing
  Tak
• DLSS / FSR
  Tak
• LED
  ASUS Aura Sync

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Nie

• Długość
  310 mm
• Wysokość
  135 mm
• Width
  60 mm
• Szerokość (szczeliny)
  3 PCIe-Slots
• Weight
  --

• Interfejs GPU
  PCIe 3.0 x 16
• Data wydania
  Q3/2018
• Release price
  1,699 $
• Proces technologiczny
  12 nm
• Część nr
  ROG-MATRIX-RTX2080TI-P11G-GAMING
• specyfikacja
  data sheet

Wspólne stanowiska ASUS ROG Matrix GeForce RTX 2080 Ti Platinum GPU w popularnych benchmarkach, dla porównania z innymi modelami.

• FP32 Performance (Single-precision TFLOPS)
  759 place
• Battlefield 5
  420 place
• Shadow of the Tomb Raider
  484 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  524 place
• Crypto-Mining Ergo Hashrate (MH/s)
  747 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  361 place
• 3DMark Benchmark
  389 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  338 place
