Graphics card PNY GeForce RTX 3050 8GB VERTO Dual Fan, specifications and benchmarks

This section outlines the key features of the graphics card PNY GeForce RTX 3050 8GB VERTO Dual Fan.

• Based on
  NVIDIA GeForce RTX 3050
• GPU Chip
  GA106-150-A1 (Ampere)
• Execution units
  20
• Shader
  2560
• Render Output Units
  48
• Texture Units
  80
• Raytracing Cores
  20

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Clock
  1.750 GHz
• Memory Speed
  14 Gbps
• Memory Bandwith
  224 GB/s
• Memory Interface
  128 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. PNY GeForce RTX 3050 8GB VERTO Dual Fan.

• Base Clock
  1.552 GHz
• Boost Clock
  1.777 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  130 W
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. PNY GeForce RTX 3050 8GB VERTO Dual Fan.

• Fan-Type
  Axial
• Fan 1
  2 x 90 mm
• Fan 2
  --
• Cooler-Type
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2 (Ultimate)
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP8
  Decode
• VP9
  Decode
• AV1
  Decode

• Length
  228 mm
• Height
  114 mm
• Width
  43 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q4/2022
• Release price
  --
• Structure size
  8 nm
• Part-no
  VCG30508DFBPB1
• Documents
  data sheet

Common positions PNY GeForce RTX 3050 8GB VERTO Dual Fan GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1559 place
• Battlefield 5
  1779 place
• Shadow of the Tomb Raider
  1915 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  2660 place
• Crypto-Mining Ergo Hashrate (MH/s)
  2642 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  2074 place
• 3DMark Benchmark
  2179 place
• Cyberpunk 2077
  47 place
• GTA 5 Benchmark (Grand Theft Auto V)
  39 place
