Graphics card NVIDIA GeForce RTX 3050, specifications and benchmarks

This section outlines the key features of the graphics card NVIDIA GeForce RTX 3050.

• Based on
  NVIDIA GeForce RTX 3050
• GPU Chip
  GA106-150-A1 (Ampere)
• Execution units
  20
• Shader
  2560
• Render Output Units
  48
• Texture Units
  80
• Raytracing Cores
  20

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Clock
  1.750 GHz
• Memory Speed
  14 Gbps
• Memory Bandwith
  224 GB/s
• Memory Interface
  128 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. NVIDIA GeForce RTX 3050.

• Base Clock
  1.552 GHz
• Boost Clock
  1.777 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  130 W
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. NVIDIA GeForce RTX 3050.

• Fan-Type
  Axial
• Fan 1
  --
• Fan 2
  --
• Cooler-Type
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  2x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2 (Ultimate)
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP8
  Decode
• VP9
  Decode
• AV1
  Decode

• Length
  --
• Height
  --
• Width
  --
• Width (Slots)
  --
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q1/2022
• Release price
  --
• Structure size
  8 nm
• Part-no
  --
• Documents
  data sheet

Common positions NVIDIA GeForce RTX 3050 GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1561 place
• Battlefield 5
  1742 place
• Shadow of the Tomb Raider
  1913 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  2662 place
• Crypto-Mining Ergo Hashrate (MH/s)
  2644 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  2066 place
• 3DMark Benchmark
  2177 place
• Cyberpunk 2077
  45 place
• GTA 5 Benchmark (Grand Theft Auto V)
  41 place
