Graphics card Colorful iGame GeForce GTX 1080 U-TOP-8G-V, specifications and benchmarks

This section outlines the key features of the graphics card Colorful iGame GeForce GTX 1080 U-TOP-8G-V.

• Based on
  NVIDIA GeForce GTX 1080
• GPU Chip
  GP104-400-A1 / GP104-410-A1
• Execution units
  20
• Shader
  2560
• Render Output Units
  64
• Texture Units
  160

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR5X
• Memory Speed
  1.251 GHz
• Memory Bandwith
  320 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. Colorful iGame GeForce GTX 1080 U-TOP-8G-V.

• Base Clock
  1.607 GHz
• Boost Clock
  1.784 GHz+ 3 %
• Avg (Game) Clock
  1.733 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  180 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. Colorful iGame GeForce GTX 1080 U-TOP-8G-V.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 80 mm
• Noise (Idle)
  --
• Fan 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.2
• HDMI Ports
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4
• DVI Ports
  1
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_1
• Raytracing
  No
• DLSS / FSR
  No
• LED
  iGame Energy Core

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Length
  --
• Height
  --
• Width
  --
• Width (Slots)
  --
• Weight
  --

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q2/2016
• Release price
  --
• Structure size
  16 nm
• Part-no
  --
• Documents
  data sheet

Common positions Colorful iGame GeForce GTX 1080 U-TOP-8G-V GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1558 place
• Battlefield 5
  1627 place
• Shadow of the Tomb Raider
  1845 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1746 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1545 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1905 place
• 3DMark Benchmark
  1847 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1160 place
