グラフィックカード NVIDIA GeForce RTX 3090 Ti, 仕様とベンチマーク

This section outlines the key features of the graphics card NVIDIA GeForce RTX 3090 Ti.

• に基づいています。
  GA102
• GPUチップ
  GA102-350-A1
• シェーダー
  10752
• レンダリング出力単位
  112
• テクスチャユニット
  336
• L1 Cache
  128 KB
• L2 Cache
  6 MB

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• メモリサイズ
  24 GB
• メモリータイプ
  GDDR6X
• メモリ速度
  1.3 GHz
• メモリ帯域
  1,008 GB/s
• メモリーインターフェース
  384 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. NVIDIA GeForce RTX 3090 Ti.

• 基本周波数
  1.56 GHz
• 最大周波数
  1.86 GHz
• オーバークロッキング
  いいえ

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  450 W
• Power Connectors
  1x 16-pin

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• DP Ports
  1x HDMI 2.1 3x DisplayPort 1.4a

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• 最大解像度
  7680x4320
• DirectX
  12_2
• OpenGL
  4.6
• OpenCL
  3.0
• Vulkan
  1.3
• Shader Model
  6.6
• ぎじゅつてきなかだい
  8 nm
• 建築
  Ampere
• Bus Interface
  PCIe 4.0 x16

• Pixel Rate
  208.3 GPixel/s
• Texture Rate
  625.0 GTexel/s
• FP16 (half)
  40.00 TFLOPS
• FP32 (float)
  40.00 TFLOPS
• FP64 (double)
  625.0 GFLOPS

共通ポジション NVIDIA GeForce RTX 3090 Ti 他機種との比較のため、一般的なベンチマークでGPUを使用。.

• Passmark Performance Test GPU
  1 place
• Performance relative to other GPU chips
  25 place
