Scheda grafica GIGABYTE AORUS GeForce RTX 3070 Ti VISION OC 8G, specifiche e parametri di riferimento

This section outlines the key features of the graphics card GIGABYTE AORUS GeForce RTX 3070 Ti VISION OC 8G.

• Basato su
  NVIDIA GeForce RTX 3070 Ti
• Chip GPU
  GA104-400-A1
• Unità di esecuzione
  48
• Shader
  6144
• Unità di uscita del rendering
  96
• Unità di texture
  192

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Dimensione della memoria
  8 GB
• Tipo di memoria
  GDDR6X
• Velocità della memoria
  1.188 GHz
• Banda di memoria
  608 GB/s
• Interfaccia di memoria
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. GIGABYTE AORUS GeForce RTX 3070 Ti VISION OC 8G.

• Frequenza di base
  1.580 GHz
• Frequenza massima
  1.830 GHz+ 3 %
• Overclock
  Sì

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  290 W
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. GIGABYTE AORUS GeForce RTX 3070 Ti VISION OC 8G.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Ventilatore 1
  2 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Ventilatore 2
  1 x 80 mm
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Visualizzazioni
  4
• Versione HDCP
  2.3
• Porte HDMI
  2x HDMI v2.1
• DP Ports
  2x DP v1.4a
• Porte DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Risoluzione massima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sì
• DLSS / FSR
  Sì
• LED
  GIGABYTE RGB Fusion

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Lunghezza
  320 mm
• Altezza
  126 mm
• Width
  55 mm
• Larghezza (slot)
  3 PCIe-Slots
• Weight
  --

• Interfaccia GPU
  PCIe 4.0 x 16
• Data di rilascio
  Q2/2021
• Release price
  --
• Processo tecnologico
  8 nm
• Part-no
  GV-N307TVISION OC-8GD
• Specifica
  data sheet

Posizioni comuni GIGABYTE AORUS GeForce RTX 3070 Ti VISION OC 8G GPU in benchmark popolari, per un confronto con altri modelli.

• FP32 Performance (Single-precision TFLOPS)
  384 place
• Battlefield 5
  437 place
• Shadow of the Tomb Raider
  388 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  647 place
• Crypto-Mining Ergo Hashrate (MH/s)
  322 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  317 place
• 3DMark Benchmark
  450 place
