Graphics card SAPPHIRE PULSE AMD Radeon RX 6500 XT, specifications and benchmarks

This section outlines the key features of the graphics card SAPPHIRE PULSE AMD Radeon RX 6500 XT.

• Based on
  AMD Radeon RX 6500 XT
• GPU Chip
  Navi 24
• Execution units
  16
• Shader
  1024
• Render Output Units
  32
• Texture Units
  64

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  4 GB
• Memory Type
  GDDR6
• Memory Speed
  2.25 GHz
• Memory Bandwith
  144 GB/s
• Memory Interface
  64 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. SAPPHIRE PULSE AMD Radeon RX 6500 XT.

• Base Clock
  2.200 GHz
• Boost Clock
  2.825 GHz
• Avg (Game) Clock
  2.685 GHz+ 3 %
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  130 W+ 21 %
• TDP (up)
  --
• Tjunction max
  110 °C
• PCIe-Power
  1 x 6-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. SAPPHIRE PULSE AMD Radeon RX 6500 XT.

• Fan-Type
  Axial
• Fan 1
  2 x 90 mm
• Fan 2
  --
• Cooler-Type
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  2
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  1x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  No
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode
• h265 / HEVC
  Decode
• VP8
  Decode
• VP9
  Decode
• AV1
  No

• Length
  194 mm
• Height
  107 mm
• Width
  40 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 4
• Release date
  Q1/2022
• Release price
  --
• Structure size
  6 nm
• Part-no
  11314-01-20G
• Documents
  data sheet

Common positions SAPPHIRE PULSE AMD Radeon RX 6500 XT GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  2257 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  2669 place
• Crypto-Mining Ergo Hashrate (MH/s)
  2894 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  2676 place
• 3DMark Benchmark
  2184 place
