Graphics card ASUS ROG Strix GeForce GTX 1660 TI OC, specifications and benchmarks

This section outlines the key features of the graphics card ASUS ROG Strix GeForce GTX 1660 TI OC.

• Based on
  NVIDIA GeForce GTX 1660 Ti
• GPU Chip
  TU116-400-A1
• Execution units
  24
• Shader
  1536
• Render Output Units
  48
• Texture Units
  96

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  6 GB
• Memory Type
  GDDR6
• Memory Speed
  1.5 GHz
• Memory Bandwith
  288 GB/s
• Memory Interface
  192 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS ROG Strix GeForce GTX 1660 TI OC.

• Base Clock
  1.500 GHz
• Boost Clock
  1.890 GHz+ 7 %
• Avg (Game) Clock
  1.860 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  120 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS ROG Strix GeForce GTX 1660 TI OC.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 90 mm
• Noise (Idle)
  --
• Fan 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  3
• HDCP-Version
  2.2
• HDMI Ports
  2x HDMI v2.0b
• DP Ports
  2x DP v1.4
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  3840x2160
• DirectX
  12_1
• Raytracing
  No
• DLSS / FSR
  No
• LED
  ASUS Aura Sync

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Length
  301 mm
• Height
  132 mm
• Width
  50 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q1/2019
• Release price
  --
• Structure size
  12 nm
• Part-no
  ROG-STRIX-GTX1660TI-O6G-GAMING
• Documents
  data sheet

Common positions ASUS ROG Strix GeForce GTX 1660 TI OC GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  2254 place
• Battlefield 5
  1937 place
• Shadow of the Tomb Raider
  1955 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  2165 place
• Crypto-Mining Ergo Hashrate (MH/s)
  2196 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  2062 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1768 place
