Graphics card SAPPHIRE Nitro+ Radeon RX 6650 XT, specifications and benchmarks

This section outlines the key features of the graphics card SAPPHIRE Nitro+ Radeon RX 6650 XT.

• Based on
  AMD Radeon RX 6650 XT
• GPU Chip
  Navi 23 KXT (RDNA 2)
• Execution units
  32
• Shader
  2048
• Render Output Units
  64
• Texture Units
  128
• Raytracing Cores
  32

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Clock
  2.190 GHz
• Memory Speed
  17.5 Gbps
• Memory Bandwith
  280 GB/s
• Memory Interface
  128 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. SAPPHIRE Nitro+ Radeon RX 6650 XT.

• Base Clock
  2.055 GHz
• Boost Clock
  2.694 GHz+ 2 %
• Avg (Game) Clock
  2.523 GHz+ 5 %
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  203 W+ 15 %
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. SAPPHIRE Nitro+ Radeon RX 6650 XT.

• Fan-Type
  Axial
• Fan 1
  2 x 90 mm
• Fan 2
  --
• Cooler-Type
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2 (Ultimate)
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  Addressable LED

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP8
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  Decode

• Length
  260 mm
• Height
  130 mm
• Width
  58 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 8
• Release date
  Q2/2022
• Release price
  --
• Structure size
  7 nm
• Part-no
  11319-01-20G
• Documents
  data sheet

Common positions SAPPHIRE Nitro+ Radeon RX 6650 XT GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1236 place
• Battlefield 5
  1389 place
• Shadow of the Tomb Raider
  1495 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  2312 place
• 3DMark Benchmark
  1161 place
• Cyberpunk 2077
  40 place
• GTA 5 Benchmark (Grand Theft Auto V)
  33 place
