Graphics card ASUS Dual Radeon RX 580 OC 8G, specifications and benchmarks

This section outlines the key features of the graphics card ASUS Dual Radeon RX 580 OC 8G.

• Based on
  AMD Radeon RX 580
• GPU Chip
  Polaris 20 XT
• Execution units
  36
• Shader
  2304
• Render Output Units
  32
• Texture Units
  144

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR5
• Memory Speed
  2 GHz
• Memory Bandwith
  256 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS Dual Radeon RX 580 OC 8G.

• Base Clock
  1.257 GHz
• Boost Clock
  1.380 GHz+ 3 %
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  185 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS Dual Radeon RX 580 OC 8G.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 90 mm
• Noise (Idle)
  --
• Fan 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.2
• HDMI Ports
  2x HDMI v2.0b
• DP Ports
  2x DP v1.4
• DVI Ports
  1
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12
• Raytracing
  No
• DLSS / FSR
  No
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Length
  242 mm
• Height
  129 mm
• Width
  38 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q4/2017
• Release price
  --
• Structure size
  14 nm
• Part-no
  DUAL-RX580-O8G
• Documents
  data sheet

Common positions ASUS Dual Radeon RX 580 OC 8G GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  2229 place
• Battlefield 5
  2416 place
• Shadow of the Tomb Raider
  2346 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1895 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1918 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  2164 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1263 place
