Carte graphique Gainward GeForce RTX 3070 Phoenix GS, spécifications et caractéristiques de référence

This section outlines the key features of the graphics card Gainward GeForce RTX 3070 Phoenix GS.

• Sur la base de
  NVIDIA GeForce RTX 3070
• Puce GPU
  GA104-300-A1
• Unités d'exécution
  46
• Shader
  5888
• Unités de sortie de rendu
  96
• Unités de texture
  184

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Taille de la mémoire
  8 GB
• Type de mémoire
  GDDR6
• Vitesse de la mémoire
  1.75 GHz
• Bande de mémoire
  448 GB/s
• Interface mémoire
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. Gainward GeForce RTX 3070 Phoenix GS.

• Fréquence de base
  1.500 GHz
• Fréquence maximale
  1.770 GHz+ 3 %
• Overclocking
  Oui

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  240 W+ 9 %
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. Gainward GeForce RTX 3070 Phoenix GS.

• Type de ventilateur
  Axial
• Type de refroidisseur
  Air cooling
• Ventilateur 1
  3 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Ventilateur 2
  --
• Noise (Load)
  41-43 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Affichages
  4
• Version HDCP
  2.3
• Ports HDMI
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• Ports DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Résolution maximale
  7680x4320
• DirectX
  12_2
• Raytracing
  Oui
• DLSS / FSR
  Oui
• LED
  Addressable LED

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Longueur
  294 mm
• Hauteur
  112 mm
• Width
  --
• Largeur (fentes)
  3 PCIe-Slots
• Weight
  --

• Interface GPU
  PCIe 4.0 x 16
• Date de sortie
  Q4/2020
• Release price
  629 $
• Processus technologique
  8 nm
• Part-no
  NE63070S19P2-1041X
• spécification
  data sheet

Positions communes Gainward GeForce RTX 3070 Phoenix GS GPU dans des benchmarks populaires, pour comparaison avec d'autres modèles.

• FP32 Performance (Single-precision TFLOPS)
  494 place
• Battlefield 5
  571 place
• Shadow of the Tomb Raider
  630 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  425 place
• Crypto-Mining Ergo Hashrate (MH/s)
  352 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  583 place
• 3DMark Benchmark
  608 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  173 place
