Graphics card PowerColor Liquid Devil Radeon RX 6900 XT, specifications and benchmarks

This section outlines the key features of the graphics card PowerColor Liquid Devil Radeon RX 6900 XT.

• Based on
  AMD Radeon RX 6900 XT
• GPU Chip
  Navi 21
• Execution units
  80
• Shader
  5120
• Render Output Units
  128
• Texture Units
  320

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  16 GB
• Memory Type
  GDDR6
• Memory Speed
  2 GHz
• Memory Bandwith
  512 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. PowerColor Liquid Devil Radeon RX 6900 XT.

• Base Clock
  1.825 GHz
• Boost Clock
  2.365 GHz+ 5 %
• Avg (Game) Clock
  2.135 GHz+ 6 %
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  300 W
• TDP (up)
  345 W
• Tjunction max
  --
• PCIe-Power
  3 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. PowerColor Liquid Devil Radeon RX 6900 XT.

• Fan-Type
  --
• Cooler-Type
  Water cooling
• Fan 1
  --
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  0 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  2x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  1

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  No
• LED
  Addressable LED

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  Decode

• Length
  266 mm
• Height
  162 mm
• Width
  42 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q2/2021
• Release price
  --
• Structure size
  7 nm
• Part-no
  AXRX 6900XT 16GBD6-W2DHC/OC
• Documents
  data sheet

Common positions PowerColor Liquid Devil Radeon RX 6900 XT GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  339 place
• Battlefield 5
  72 place
• Shadow of the Tomb Raider
  265 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  351 place
• Crypto-Mining Ergo Hashrate (MH/s)
  702 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  562 place
• 3DMark Benchmark
  194 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  372 place
