Graphics card Palit GeForce RTX 3070 JetStream, specifications and benchmarks

This section outlines the key features of the graphics card Palit GeForce RTX 3070 JetStream.

• Based on
  NVIDIA GeForce RTX 3070
• GPU Chip
  GA104-300-A1
• Execution units
  46
• Shader
  5888
• Render Output Units
  96
• Texture Units
  184

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Speed
  1.75 GHz
• Memory Bandwith
  448 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. Palit GeForce RTX 3070 JetStream.

• Base Clock
  1.500 GHz
• Boost Clock
  1.725 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  250 W+ 14 %
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. Palit GeForce RTX 3070 JetStream.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  2 x 100 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  43-44 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  Addressable LED

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Length
  304 mm
• Height
  136 mm
• Width
  60 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q4/2020
• Release price
  599 $
• Structure size
  8 nm
• Part-no
  NE63070019P2-1040J
• Documents
  data sheet

Common positions Palit GeForce RTX 3070 JetStream GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  575 place
• Battlefield 5
  707 place
• Shadow of the Tomb Raider
  695 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  441 place
• Crypto-Mining Ergo Hashrate (MH/s)
  436 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  646 place
• 3DMark Benchmark
  705 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  202 place
