Graphics card MSI Radeon RX 6950 XT GAMING X TRIO 16G, specifications and benchmarks

This section outlines the key features of the graphics card MSI Radeon RX 6950 XT GAMING X TRIO 16G.

• Based on
  AMD Radeon RX 6950 XT
• GPU Chip
  Navi 21 KXTX (RDNA 2)
• Execution units
  80
• Shader
  5120
• Render Output Units
  128
• Texture Units
  320
• Raytracing Cores
  80

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  16 GB
• Memory Type
  GDDR6
• Memory Clock
  2.250 GHz
• Memory Speed
  18 Gbps
• Memory Bandwith
  576 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. MSI Radeon RX 6950 XT GAMING X TRIO 16G.

• Base Clock
  1.925 GHz
• Boost Clock
  2.454 GHz+ 6 %
• Avg (Game) Clock
  2.244 GHz+ 6 %
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  340 W+ 1 %
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  3 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. MSI Radeon RX 6950 XT GAMING X TRIO 16G.

• Fan-Type
  Axial
• Fan 1
  3 x 90 mm
• Fan 2
  --
• Cooler-Type
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2 (Ultimate)
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  MSI Mystic Light

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP8
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  Decode

• Length
  325 mm
• Height
  140 mm
• Width
  55 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q2/2022
• Release price
  --
• Structure size
  7 nm
• Part-no
  --
• Documents
  data sheet

Common positions MSI Radeon RX 6950 XT GAMING X TRIO 16G GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  324 place
• Battlefield 5
  28 place
• Shadow of the Tomb Raider
  189 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  702 place
• Crypto-Mining Ergo Hashrate (MH/s)
  863 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  912 place
• 3DMark Benchmark
  30 place
• Cyberpunk 2077
  17 place
• GTA 5 Benchmark (Grand Theft Auto V)
  22 place
