Graphics card MSI GeForce RTX 2080 Sea Hawk X, specifications and benchmarks

This section outlines the key features of the graphics card MSI GeForce RTX 2080 Sea Hawk X.

• Based on
  NVIDIA GeForce RTX 2080
• GPU Chip
  TU104
• Execution units
  46
• Shader
  2944
• Render Output Units
  64
• Texture Units
  184

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Speed
  1.75 GHz
• Memory Bandwith
  448 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. MSI GeForce RTX 2080 Sea Hawk X.

• Base Clock
  1.515 GHz
• Boost Clock
  1.860 GHz+ 9 %
• Avg (Game) Clock
  1.710 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  245 W+ 14 %
• TDP (up)
  285 W+ 20 %
• Tjunction max
  89 °C
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. MSI GeForce RTX 2080 Sea Hawk X.

• Fan-Type
  Axial
• Cooler-Type
  AIO water cooling
• Fan 1
  1 x 65 mm
• Noise (Idle)
  35 dB
• Fan 2
  1 x 120 mm
• Noise (Load)
  45 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.2
• HDMI Ports
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  1

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Length
  268 mm
• Height
  114 mm
• Width
  41 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  1370 g

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q3/2018
• Release price
  849 $
• Structure size
  12 nm
• Part-no
  --
• Documents
  data sheet

Common positions MSI GeForce RTX 2080 Sea Hawk X GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1247 place
• Battlefield 5
  1113 place
• Shadow of the Tomb Raider
  981 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1146 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1617 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  672 place
• 3DMark Benchmark
  965 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  816 place
