Graphics card GIGABYTE GeForce RTX 3060 Ti Vision 8G LHR, specifications and benchmarks

This section outlines the key features of the graphics card GIGABYTE GeForce RTX 3060 Ti Vision 8G LHR.

• Based on
  NVIDIA GeForce RTX 3060 Ti LHR
• GPU Chip
  GA104-202-A1
• Execution units
  38
• Shader
  4864
• Render Output Units
  80
• Texture Units
  152

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Speed
  1.75 GHz
• Memory Bandwith
  448 GB/s
• Memory Interface
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. GIGABYTE GeForce RTX 3060 Ti Vision 8G LHR.

• Base Clock
  1.410 GHz
• Boost Clock
  1.665 GHz-15 %
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  200 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. GIGABYTE GeForce RTX 3060 Ti Vision 8G LHR.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 80 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  36 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  2x HDMI v2.1
• DP Ports
  2x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  GIGABYTE RGB Fusion

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Length
  281 mm
• Height
  115 mm
• Width
  40 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q3/2021
• Release price
  --
• Structure size
  8 nm
• Part-no
  GV-N306TVISION-8GD
• Documents
  data sheet

Common positions GIGABYTE GeForce RTX 3060 Ti Vision 8G LHR GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  731 place
• Battlefield 5
  1008 place
• Shadow of the Tomb Raider
  861 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1102 place
• Crypto-Mining Ergo Hashrate (MH/s)
  575 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1265 place
• 3DMark Benchmark
  885 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1333 place
