Graphics card ASUS ROG Strix GeForce RTX 3060 OC Edition, specifications and benchmarks

This section outlines the key features of the graphics card ASUS ROG Strix GeForce RTX 3060 OC Edition.

• Based on
  NVIDIA GeForce RTX 3060
• GPU Chip
  GA106-300-A1
• Execution units
  28
• Shader
  3584
• Render Output Units
  64
• Texture Units
  112

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  12 GB
• Memory Type
  GDDR6
• Memory Speed
  1.875 GHz
• Memory Bandwith
  360 GB/s
• Memory Interface
  192 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS ROG Strix GeForce RTX 3060 OC Edition.

• Base Clock
  1.320 GHz
• Boost Clock
  1.912 GHz+ 7 %
• Avg (Game) Clock
  1.882 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  170 W
• TDP (up)
  210 W+ 24 %
• Tjunction max
  --
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS ROG Strix GeForce RTX 3060 OC Edition.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 95 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  32-34 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  2x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  ASUS Aura Sync

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Length
  300 mm
• Height
  134 mm
• Width
  54 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  1123 g

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q1/2021
• Release price
  579 $
• Structure size
  8 nm
• Part-no
  ROG-STRIX-RTX3060-O12G-GAMING
• Documents
  data sheet

Common positions ASUS ROG Strix GeForce RTX 3060 OC Edition GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  837 place
• Battlefield 5
  1301 place
• Shadow of the Tomb Raider
  1070 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1805 place
• Crypto-Mining Ergo Hashrate (MH/s)
  888 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1230 place
• 3DMark Benchmark
  1477 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1690 place
