Intel Core i7-3770K
Select processor 2
Select video card 1
Select video card 2
Overall score
star star star star star
Released
Q2/2012
Intel Core i7-3770K

Processor Intel Core i7-3770K, specifications and benchmarks

860 place in the overall ranking CPUs!
The Intel Core i7-3770K processor is installed in LGA 1155 socket boards and operates at a frequency of 3.50 GHz. The Intel Core i7-3770K has a total of 4 cores. Release date: Q2/2012. TDP is 77 W. This review will provide all the technical specifications and detailed data about the Intel Core i7-3770K processor. Discover everything to determine whether a game or software will run on Intel Core i7-3770K.

Specifications

Technical data
CPU Family and Group

This section provides a comprehensive overview of the processors generation and family, explaining the specific market segment it is designed for. It covers key details such as the CPUs position within its product lineup, its intended use cases (e.g., consumer, server, or workstation), and how its generation compares to previous models.

  • Segment
    Desktop / Server
  • Family
  • Generation
    3
  • CPU group
    Intel Core i 3000
  • Predecessor
    --
  • Successor
    --
CPU Technical Specs

Intel Core i7-3770K. This section highlights key performance parameters of the processor, including the number of cores, threads, and clock speeds (base and boost frequencies). These metrics directly impact multitasking capabilities and overall system performance in both single-threaded and multi-threaded applications.

  • Frequency
    3.50 GHz
  • CPU Cores
    4
  • Turbo (1 Core)
    3.90 GHz
  • CPU Threads
    8
  • Turbo (4 Cores)
    3.90 GHz
  • Hyperthreading
    Yes
  • Overclocking
    Yes
  • Core architecture
    normal
  • A core
    --
  • B core
    --
  • C core
    --
IGPU

This section provides details on the integrated graphics capabilities of the processor. It covers the architecture, performance characteristics, and supported technologies (e.g., DirectX, OpenGL), which are essential for systems without dedicated GPUs or for mobile devices that require energy-efficient graphics processing.

  • GPU name
    Intel HD Graphics 4000
  • GPU frequency
    0.65 GHz
  • GPU (Turbo)
    1.15 GHz
  • Execution units
    16
  • Shader
    128
  • Max. GPU Memory
    --
  • Max. displays
    3
  • Generation
    7
  • DirectX Version
    11.0
  • Technology
    22 nm
  • Release date
    Q1/2011
Hardware codec support

This section covers the built-in hardware codec support for video and image processing. The processor’s ability to handle codecs like H.264, HEVC, and VP9 directly influences its performance in tasks such as video playback, editing, and streaming. This hardware acceleration ensures smoother media handling with lower CPU utilization.

  • h265 / HEVC (8 bit)
    No
  • h265 / HEVC (10 bit)
    No
  • h264
    Decode / Encode
  • VP9
    No
  • VP8
    No
  • AV1
    No
  • AVC
    Decode / Encode
  • VC-1
    Decode
  • JPEG
    Decode
Memory Specs & PCI

This section breaks down the technical characteristics of the memory supported by the processor, including the types (e.g., DDR4, DDR5), number of memory channels, and maximum supported memory speed. It also covers PCI Express support, which determines the bandwidth available for GPUs, SSDs, and other peripherals, critical for high-performance systems.

  • Memory type
    DDR3-1600
  • Max. Memory
    32 GB
  • ECC
    No
  • Memory channels
    2
  • PCIe version
    3.0
  • PCIe lanes
    16
Encryption

This section focuses on the hardware-based security technologies integrated into the processor. These include encryption support features such as AES-NI, Intel SGX, and AMD Secure Memory Encryption, which provide robust protection for sensitive data and help mitigate cybersecurity risks.

  • AES-NI
    Yes
Thermal Management
  • TDP (PL1)
    77 W
  • TDP up
    --
  • TDP (PL2)
    --
  • TDP down
    --
  • Tjunction max.
    --
* see below
Technologies and Extensions

This section explains the underlying technologies that enable the processor to deliver high performance. It includes details about the manufacturing process (e.g., 7nm, 10nm), supported instruction sets (e.g., AVX, SSE), and virtual machine extensions that enhance compatibility and efficiency across various workloads.

  • Instruction set (ISA)
    x86-64 (64 bit)
  • Virtualization
    VT-x, VT-x EPT, VT-d
  • ISA extensions
    SSE4.1, SSE4.2, AVX
  • L2-Cache
    --
  • L3-Cache
    8.00 MB
  • Architecture
    Ivy Bridge S
  • Technology
    22 nm
  • Socket
    LGA 1155
  • Release date
    Q2/2012
  • Part Number
    --
Positions in all rankings

Common positions Intel Core i7-3770K CPU in popular benchmarks, for comparison with other models.

  • Cinebench R20 (Single-Core)
    469 place
  • Cinebench R20 (Multi-Core)
    359 place
  • Cinebench R15 (Single-Core)
    564 place
  • Cinebench R15 (Multi-Core)
    445 place
  • Geekbench 5, 64bit (Single-Core)
    677 place
  • Geekbench 5, 64bit (Multi-Core)
    695 place
  • iGPU - FP32 Performance (Single-precision GFLOPS)
    1163 place
  • Blender 2.81 (bmw27)
    55 place
  • Geekbench 3, 64bit (Single-Core)
    236 place
  • Geekbench 3, 64bit (Multi-Core)
    241 place
  • Cinebench R11.5, 64bit (Single-Core)
    329 place
  • Cinebench R11.5, 64bit (Multi-Core)
    250 place
  • Cinebench R11.5, 64bit (iGPU, OpenGL)
    304 place
  • Estimated results for PassMark CPU Mark
    735 place

Benchmarks

Performance tests CPU

Compare the benchmark scores of Intel Core i7-3770K with other processors to gauge its real-world performance across various tasks..

These tests encompass tasks such as mathematical calculations, 3D rendering, cryptocurrency mining, and performance evaluations in both single-core and multi-core modes.

Cinebench R20 (Single-Core)
Cinebench R20 SC is a high load CPU test for long tasks on a desktop or notebook PC, uses one CPU core, with no hypetrading
Cinebench R20 (Multi-Core)
Cinebench R20 MC is a high load CPU test for long tasks on a desktop or notebook PC, using a multi-core and hyperthreading
1419
1411
1400
1391
Intel Core i7-3770K
Cinebench R15 (Single-Core)
The Cinebench R15 SC stresses the computing modules of a desktop or laptop computer to their limits and accurately determines the key performance parameters of the hardware
Cinebench R15 (Multi-Core)
The Cinebench R15 MC stresses the computing modules of a desktop or laptop computer to their limits and accurately determines the key performance parameters of the hardware
675
675
673
672
Intel Core i7-3770K
Geekbench 5, 64bit (Single-Core)
Geekbench 5 SC is a popular cross-platform performance test for desktop or mobile processors that uses system memory intensively
877
876
874
873
Intel Core i7-3770K
Geekbench 5, 64bit (Multi-Core)
Geekbench 5 MC is a popular cross-platform performance test for desktop or mobile processors that uses system memory intensively
3416
3416
3411
3409
Intel Core i7-3770K
iGPU - FP32 Performance (Single-precision GFLOPS)
The performance of the iGPU - the internal GPU in games
307
304
304
294
Intel Core i7-3770K
Blender 2.81 (bmw27)
Blender is Open Source Software, creating predefined 3D scenes and measuring the time to execute them
574.1
576.6
581
597.4
Intel Core i7-3770K
Geekbench 3, 64bit (Single-Core)
Geekbench 3 SC for one CPU core, includes stress tests simulating real 3D scenarios for Windows, Mac, Linux, Ansroid, iOS
3800
3789
3789
3782
Intel Core i7-3770K
Geekbench 3, 64bit (Multi-Core)
Geekbench 3 MC using a multi-core and hyperthreading, includes stress tests simulating real 3D scenarios for Windows, Mac, Linux, Ansroid, iOS
15097
15034
15022
14944
Intel Core i7-3770K
Cinebench R11.5, 64bit (Single-Core)
The PC CPU and GPU test involves rendering a specific 3D scene in single-core mode, based on CINEMA 4D
1.67
1.67
1.67
1.66
Intel Core i7-3770K
Cinebench R11.5, 64bit (Multi-Core)
The PC CPU and GPU test involves rendering a specific 3D scene in multi-core mode and hyperthreading, based on CINEMA 4D
7.7
7.64
7.61
7.61
Intel Core i7-3770K
Cinebench R11.5, 64bit (iGPU, OpenGL)
The iGPU test involves rendering a specific 3D scene, based on CINEMA 4D
13.3
13.2
13.2
13.2
Intel Core i7-3770K
Estimated results for PassMark CPU Mark
PassMark is a test suite that performs complex mathematical calculations to determine CPU performance on file compression, encryption and physics-related tasks
9687
9652
9650
9632
Intel Core i7-3770K

Synonyms

Similar processors in terms of performance.

Similar in technical data processors with Intel Core i7-3770K.

AMD Ryzen 3 PRO 1200 View
Intel Core i3-9100 View
Intel Pentium G4620 View
Intel Core i5-9300H View
Intel Processor N97 View
Intel Core i5-11400T View
Intel Core i7-4930MX View
AMD Ryzen 5 2500U View

*

PL1 - The power limit (in watts) generated by the processor (or GPU) during sustained, standard operation. It represents the typical thermal output during normal workloads.

PL2 - Represents the maximum power limit under heavy load or overclocking conditions. It indicates the thermal output during peak performance.

These values are essential for determining the optimal cooling system and power supply required to maintain stable performance.
