Intel Atom Z3745
Select processor 2
Select video card 1
Select video card 2
Overall score
star star star star star
Released
Q1/2014
Intel Atom Z3745

Processor Intel Atom Z3745, specifications and benchmarks

1744 place in the overall ranking CPUs!
The Intel Atom Z3745 processor is installed in BGA 1380 socket boards and operates at a frequency of 1.33 GHz. The Intel Atom Z3745 has a total of 4 cores. Release date: Q1/2014. TDP is 4 W. This review will provide all the technical specifications and detailed data about the Intel Atom Z3745 processor. Discover everything to determine whether a game or software will run on Intel Atom Z3745.

Specifications

Technical data
CPU Family and Group

This section provides a comprehensive overview of the processors generation and family, explaining the specific market segment it is designed for. It covers key details such as the CPUs position within its product lineup, its intended use cases (e.g., consumer, server, or workstation), and how its generation compares to previous models.

  • Segment
    Mobile
  • Family
  • Generation
    4
  • CPU group
    Intel Atom Z3700
  • Predecessor
    --
  • Successor
    --
CPU Technical Specs

Intel Atom Z3745. This section highlights key performance parameters of the processor, including the number of cores, threads, and clock speeds (base and boost frequencies). These metrics directly impact multitasking capabilities and overall system performance in both single-threaded and multi-threaded applications.

  • Frequency
    1.33 GHz
  • CPU Cores
    4
  • Turbo (1 Core)
    1.86 GHz
  • CPU Threads
    4
  • Turbo (4 Cores)
    No turbo
  • Hyperthreading
    No
  • Overclocking
    No
  • Core architecture
    normal
  • A core
    --
  • B core
    --
  • C core
    --
IGPU

This section provides details on the integrated graphics capabilities of the processor. It covers the architecture, performance characteristics, and supported technologies (e.g., DirectX, OpenGL), which are essential for systems without dedicated GPUs or for mobile devices that require energy-efficient graphics processing.

  • GPU name
    Intel HD Graphics (Bay Trail GT1)
  • GPU frequency
    0.31 GHz
  • GPU (Turbo)
    0.78 GHz
  • Execution units
    4
  • Shader
    32
  • Max. GPU Memory
    8 GB
  • Max. displays
    2
  • Generation
    7
  • DirectX Version
    11.2
  • Technology
    22 nm
  • Release date
    Q3/2013
Hardware codec support

This section covers the built-in hardware codec support for video and image processing. The processor’s ability to handle codecs like H.264, HEVC, and VP9 directly influences its performance in tasks such as video playback, editing, and streaming. This hardware acceleration ensures smoother media handling with lower CPU utilization.

  • h265 / HEVC (8 bit)
    No
  • h265 / HEVC (10 bit)
    No
  • h264
    Decode / Encode
  • VP9
    No
  • VP8
    No
  • AV1
    No
  • AVC
    Decode / Encode
  • VC-1
    Decode
  • JPEG
    Decode
Memory Specs & PCI

This section breaks down the technical characteristics of the memory supported by the processor, including the types (e.g., DDR4, DDR5), number of memory channels, and maximum supported memory speed. It also covers PCI Express support, which determines the bandwidth available for GPUs, SSDs, and other peripherals, critical for high-performance systems.

  • Memory type
    LPDDR3-1066
  • Max. Memory
    4 GB
  • ECC
    No
  • Memory channels
    2
  • PCIe version
  • PCIe lanes
Encryption

This section focuses on the hardware-based security technologies integrated into the processor. These include encryption support features such as AES-NI, Intel SGX, and AMD Secure Memory Encryption, which provide robust protection for sensitive data and help mitigate cybersecurity risks.

  • AES-NI
    Yes
Thermal Management
  • TDP (PL1)
    4 W
  • TDP up
    --
  • TDP (PL2)
    --
  • TDP down
    --
  • Tjunction max.
    90 °C
* see below
Technologies and Extensions

This section explains the underlying technologies that enable the processor to deliver high performance. It includes details about the manufacturing process (e.g., 7nm, 10nm), supported instruction sets (e.g., AVX, SSE), and virtual machine extensions that enhance compatibility and efficiency across various workloads.

  • Instruction set (ISA)
    x86-64 (64 bit)
  • Virtualization
    VT-x, VT-x EPT
  • ISA extensions
    SSE4.1, SSE4.2
  • L2-Cache
    --
  • L3-Cache
    2.00 MB
  • Architecture
    Bay Trail
  • Technology
    22 nm
  • Socket
    BGA 1380
  • Release date
    Q1/2014
  • Part Number
    --
Positions in all rankings

Common positions Intel Atom Z3745 CPU in popular benchmarks, for comparison with other models.

  • iGPU - FP32 Performance (Single-precision GFLOPS)
    1682 place
  • Geekbench 3, 64bit (Single-Core)
    872 place
  • Geekbench 3, 64bit (Multi-Core)
    813 place
  • Estimated results for PassMark CPU Mark
    1333 place

Benchmarks

Performance tests CPU

Compare the benchmark scores of Intel Atom Z3745 with other processors to gauge its real-world performance across various tasks..

These tests encompass tasks such as mathematical calculations, 3D rendering, cryptocurrency mining, and performance evaluations in both single-core and multi-core modes.

iGPU - FP32 Performance (Single-precision GFLOPS)
The performance of the iGPU - the internal GPU in games
51
50
50
50
Intel Atom Z3745
Geekbench 3, 64bit (Single-Core)
Geekbench 3 SC for one CPU core, includes stress tests simulating real 3D scenarios for Windows, Mac, Linux, Ansroid, iOS
815
810
802
796
Intel Atom Z3745
Geekbench 3, 64bit (Multi-Core)
Geekbench 3 MC using a multi-core and hyperthreading, includes stress tests simulating real 3D scenarios for Windows, Mac, Linux, Ansroid, iOS
2768
2768
2732
2716
Intel Atom Z3745
Estimated results for PassMark CPU Mark
PassMark is a test suite that performs complex mathematical calculations to determine CPU performance on file compression, encryption and physics-related tasks
1109
1109
1093
1076
Intel Atom Z3745

Synonyms

Similar processors in terms of performance.

Similar in technical data processors with Intel Atom Z3745.

Intel Celeron 1019Y View
AMD E-300 View
HiSilicon Kirin 970 View
MediaTek Helio P22 View
Intel Atom Z3770 View
Qualcomm Snapdragon 439 View
AMD E1-1200 View
AMD E1-2100 View

*

PL1 - The power limit (in watts) generated by the processor (or GPU) during sustained, standard operation. It represents the typical thermal output during normal workloads.

PL2 - Represents the maximum power limit under heavy load or overclocking conditions. It indicates the thermal output during peak performance.

These values are essential for determining the optimal cooling system and power supply required to maintain stable performance.
